Hydraulic chuck SK 40, Ø 12 x 80,5 mm
€121.97*
Available, delivery time: 1-3 workdays
Product information "Hydraulic chuck SK 40, Ø 12 x 80,5 mm"
Hydraulic chuck DIN 69871, SK40
- DIN 69871 AD/B
- balanced G = 2,5 20.000 U/min.
- SK 40
- d: 12 mm
- L: 80,5 mm
- incl. wrench
| Size: | SK 40 |
|---|---|
| Tool holders: | DIN 69871 |
| Type: | Hydraulic chucks |
| Ø : | 12 mm |
Technical Data
| Größe / Size |
d mm |
D1 mm |
D2 mm |
L mm |
L1 mm |
C1 mm |
C mm |
| SK 40 | 6 | 28 | 50 | 80,5 | 35 | 26 | 40 |
| SK 40 | 8 | 30 | 50 | 80,5 | 35 | 28 | 40 |
| SK 40 | 10 | 32 | 50 | 80,5 | 35 | 33 | 45 |
| SK 40 | 12 | 34 | 50 | 80,5 | 35 | 37 | 47 |
| SK 40 | 16 | 38 | 50 | 80,5 | 35 | 40 | 51 |
| SK 40 | 20 | 43 | 50 | 80,5 | 35 | 40 | 51 |
| SK 50 | 20 | 43 | 52 | 90 | 34,5 | 40 | 51 |
| SK 50 | 32 | 62 | 72 | 105 | 43 | 60 | 90 |
| SK 40 Gewuchtet G = 2,5 20.000 U/min. / Balanced G = 2,5 20.000 U/min. SK 50 Gewuchtet G = 2,5 15.000 U/min. / Balanced G = 2,5 15.000 U/min. |
|||||||
| Angaben ohne Gewähr, technische Änderungen vorbehalten / Information provided without guarantee, technical changes reserved |
|||||||
Product Safety Information:
- Suitable only for technically skilled users familiar with the product and for craftsmen.
- Intended solely for the designated purpose.
- Improper use may lead to damage and injuries.
